Carefully clean the inside of the
air cleaner housing with a damp
rag.
Place the new air cleaner element
in the air cleaner housing.
The air cleaner element is inside the
air cleaner housing in the engine
compartment.
To replace it:
The air cleaner element should be
replaced according to the distance
recommendation in the maintenance
schedule.
Unsnap the four clips and remove
the air cleaner housing cover.
Remove the old air cleaner
element.
Reinstall the air cleaner housing
cover and snap the four clips back
into place.
1.
3.
2.
4.
5.
Replacement
Maintenance
Air Cleaner Element
211
CLIPS
CLIPS
AIR CLEANER ELEMENT
