U.S. Models
Canadian Models
This shows your speed in miles per
hour (mph). The smaller inner
numbers are the speed in kilometers
per hour (km/h).
This shows your speed in kilometers
per hour (km/h). The smaller inner
numbers are the speed in miles per
hour (mph).
The tachometer shows the engine
speed in revolutions per minute
(rpm). To protect the engine from
damage, never drive with the
tachometer needle in the red zone.
The odometer shows the total dis-
tance your vehicle has been driven.
It measures miles in U.S. models and
kilometers in Canadian models.
It is illegal under U.S. federal law and
Canadian provincial regulations to
disconnect, reset, or alter the
odometer with the intent to change
the number of miles or kilometers
indicated.
Speedometer
Odometer
Tachometer
Gauges
Instruments and Controls
67
TACHOMETER
SPEEDOMETER FUEL GAUGE TEMPERATURE
GAUGE
MAINTENANCE
REQUIRED INDICATOR
TRIP METER
SELECT/RESET
BUTTON
TRIP METER
ODOMETER
