To achieve a proper tongue load,
start by loading 60 % of the load
toward the front of the trailer and
40 % toward the rear, then re-adjust
the load as needed.
The maximum allowable weight of
the vehicle, all occupants, all
accessories, all cargo, and the
tongue load is:
The maximum allowable weight of
the vehicle, all occupants, all
accessories, all cargo, and the
tongue load must not exceed:
Thebestwaytoconfirmthatall
loads are within limits is to check
them at a public scale.
Using a suitable scale or a special
tongue load gauge, check the tongue
load the first time you set up a
towing combination (a fully-loaded
vehicle and trailer), then recheck the
tongue load whenever the conditions
change.
on the front axle
on the rear axle
Checking Loads
Gross Vehicle Weight Rating
(GVWR):
Gross Axle Weight Rating
(GAWR):
Towing a Trailer
174
2,300 lbs (1,045 kg)
2,205 lbs (1,000 kg)
4,450 lbs (2,020 kg)
