Push the electrical connector back
onto the bulb. Make sure it is on
all the way.
Turn on the headlights to test the
new bulb.
(Driver’s side)
Install the front end of the air
intake duct.
Insert the new bulb into the hole,
and turn it one-quarter turn
clockwise to lock it in place.
Remove the bulb by turning it one-
quarter turn counterclockwise.
Remove the electrical connector
from the bulb by pushing on the
tab and pulling the connector
down.
3.
4.
5.
6.
7.
2.
Lights
Replacing a Front Parking/Turn
Signal Light Bulb
204
TAB
On all models except SC
On SC model
０７／０４／２６ １９：０３：１９ ３１ＳＣＶ６５０ ０２０９
