Installing a Child Seat with
LATCH
Your vehicle is equipped with
LATCH (Lower Anchors and Tethers
for CHildren) at the rear seats.
The lower anchors are located
between the seat-back and seat
bottom, and are to be used only with
a child seat designed for use with
LATCH.
The location of each lower anchor is
indicated by a small button above the
anchor point.
To install a LATCH-compatible child
seat:
1. Remove both anchor covers by
pulling forward.
2. Make sure there are no objects
near the anchors that could
prevent a secure connection
between the child seat and the
anchors.
3. Place the child seat on the vehicle
seat, then attach the seat to the
lower anchors according to the
child seat maker's instructions.
Some LATCH-compatible seats
have a rigid-type connector as
shown above.
MARKS
LOWER ANCHORS
ANCHOR COVER
Rigid-type
Installing a Child Seat
44
