INSTRUMENT PANEL INDICATORS
Briefly appear with each engine start. Red and amber indicators are most critical. Blue
and green indicators are used for general information. See your Owner’s Manual for
more information.
Malfunction Indicators
If an indicator remains on, there may be a problem; see your dealer
On/Off Indicators
Condition Indicators
Action is needed by driver
PASSENGER AIRBAG OFF
(located on center panel)
SIDE AIRBAG OFF
CRUISE CONTROL on
ECO
Fuel economy on
Fog lights on*
Headlights on
Turn signals/hazards on
High beams on
*if equipped
Charging system
Low brake fluid, Brake system
Low oil pressure
ABS (anti-lock brake system)
VTM-4 (4WD only)
Malfunction lamp (check engine light)
VSA
®
(vehicle stability assist)
SRS (supplemental restraint system)
DRL (daytime running lights)
Power tailgate*
TPMS
(tire pressure monitoring system)
Parking brake on:
Release
Door/Tailgate open:
Close door(s) / tailgate
Seat belt reminder:
Fasten seat belt(s)
Maintenance Minder:
Make dealer appointment
A/T temperature (4WD only):
Pull over and let engine idle
Starter system: Hold ignition
switch in START (III) for
up to 15 seconds
Low fuel:
Refill
Low tire pressure:
Add air
Immobilizer
(blinks):
Use correct key
CRUISE MAIN on
VSA OFF
13 Pilot TRG_LE EX EXL EXLRES_ATG_NEW STYLE 8/8/2012 3:11 PM Page 4
