Compression Damping
You can adjust the compression damping by
the adjuster to suit the load or the road
surface.
The compression damping adjuster has 12
position or more.
Turn clockwise to increase compression
damping (hard), or turn counterclockwise to
decrease compression damping (soft). Turn
the adjuster clockwise (hard) until it will no
longer turn (lightly seat). Turn the adjuster
counterclockwise (soft) until it clicks.
CRF1000A/D
The standard position is 8 clicks from the
maximum setting.
CRF1000A II/D II
The standard position is 4 clicks from the
maximum setting.
NOTICE
Do not turn the adjuster beyond its limits.
Adjust both left and right forks to the same
compression damping.
20171109154101_32MKK8000_eng_BOOK Page 150 Thursday, November 09 2017 15:56:56 JST
Other Adjustments u Adjusting the Front Suspension
Maintenance
145
Adjuster

Honda Africa Twin CRF1000 2017 Specifications

General

Displacement	998 cc
Horsepower	94 hp
Bore x Stroke	92.0 mm x 75.1 mm
Compression Ratio	10.0:1
Fuel System	PGM-FI electronic fuel injection
Ignition	Full transistorized ignition
Final Drive	Chain
Front Tire	90/90-21
Rear Tire	150/70-18
Fuel Capacity	4.97 gallons
Engine Type	Liquid-cooled, 4-stroke, 8-valve, parallel-twin
Max Power Output	70 kW @ 7, 500 rpm
Torque	98 Nm @ 6, 000 rpm
Transmission	6-speed
Front Suspension	45mm inverted telescopic fork
Rear Suspension	Pro-Link with gas-charged damper, 220mm travel
Front Brake	Dual 310mm wave disc with 4-piston calipers
Rear Brake	256mm hydraulic disc with ABS
Wheelbase	62.0 inches
Seat Height	34.3 / 33.5 inches (adjustable)
Wet Weight	228 kg (503 lbs)
Curb Weight	228 kg (503 lbs)
Kerb Weight	511 pounds
Traction Control	Selectable Torque Control (HSTC)
