Electrical Trouble u Blown Fuse
337
#
FI Fuse & Main 2 Fuse & DCT Main
Fuse
1.
Remove the battery box cover. 2 P. 268
2.
Pull the main 2 fuse/FI main fuse box and
DCT fuse box suspension out.
3.
Open the fuse box covers.
4.
Pull the FI fuse, main 2 fuse and DCT main
fuse out with the fuse puller provided on
the underside of the rear seat (
2 P. 242)
one by one check for a blown fuse. Always
replace a blown fuse with a spare fuse of
the same rating.
u Spare FI fuse is provided in the fuse box
under the front seat.
2 P. 334
u Spare main 2 fuse and spare DCT main
fuse are provided in the starter magnetic
switch.
5.
Reinstall parts in the reverse order of
removal.
DCT main fuse
FI fuse
Main 2 fuse
Fuse box covers
Main 2 fuse/FI main
fuse box and DCT
fuse box suspension
If a fuse fails repeatedly, you likely have an electrical
problem. Have your vehicle inspected by your dealer.
