uuFusesuFuse Locations
Continued
Handling the Unexpected
■
Circuit protected and fuse rating
Circuit Protected Amps
1 BATTERY 125 A
2
-40 A
-40 A
F/BOX OPTION 60 A
-40 A
F/BOX OPTION2 40 A
DC/DC2 (30 A)
F/BOX MAIN 60 A
3
- 40 A
- 40 A
- 40 A
RR DEFROSTER 40 A
- 40 A
HTR MTR 40 A
- 40 A
4
-30 A
ABS/VSA MTR 40 A
DC/DC (30 A)
-30 A
IG MAIN 30 A
-30 A
R/M2 30 A
5
ST MAGNETIC SW 30 A
WIPER 30 A
EPS 70 A
R/M1
*
30 A
ABS/VSA FSR 40 A
MAIN FAN 30 A
F/BOX MAIN2 40 A
6 SUB FAN 30 A
7 IG MAIN2 30 A
8- -
9 EVP
*
(30 A)
10 AUDIO SUB
*
(7.5 A)
11 - -
12 - -
13 H/STRG
*
(10 A)
14 - -
15 FR FOG
*
(10 A)
16 MG CLUTCH 10 A
17 WASHER 15 A
18 HORN 10 A
19 BACK UP 15 A
20 AUDIO (15 A)
21 - -
22 DBW 15 A
23 EOP
*
(20 A)
24 BACKUP FI-ECU 10 A
25 IGP 15 A
Circuit Protected Amps
26 TCU
*
(15 A)
27 LCM L (15 A)
28 INJ
*
(15 A)
29 STOP 10 A
30 LCM R (15 A)
31 IG COIL 15 A
32 - -
33 HAZARD 15 A
34 AUDIO SUB VST
*
(7.5 A)
35 - -
36 AUDIO VST MAIN (30 A)
37 BACKUP2 (30 A)
38 - -
39 - -
40 VBACT
*
(10 A)
41 IGPS [LAF] 10 A
42 IG1 MON2 7.5 A
Circuit Protected Amps
* Not available on all models
