The under-bonnet fuse box is located
in the back of the engine
compartment on the left side. To
open it, push the tabs as shown.
The secondary fuse box is located in
the front of the engine compartment.
To open it, push the tabs as shown.
The vehicle’s fuses are contained in
threefuseboxes.
The interior fuse box is underneath
the dashboard on the driver’s side.
Fuses
Taking Care of the Unexpected
299
TAB
INTERIOR UNDER-BONNET (PRIMARY) UNDER-BONNET (SECONDARY)
TAB
TAB
FUSE BOX
FUSE LABEL
07/08/22 17:54:41 32SND620_304
