Honda CRF150F User Manual

78
BRAKE SHOE WEAR
Refer to the Safety Precautions on page 44.
The rear brake is equipped with a brake wear
indicator.
When the brake is applied, an arrow (1)
attached to the brake arm (2) moves toward
a reference mark (3) on the brake panel (4).
If the arrow aligns with the reference mark
on full application of the brake, the brake
shoes must be replaced.
See your Honda dealer for this service.
When the brake service is necessary, see
your Honda dealer. Use only genuine Honda
parts or its equivalent.
(1) Arrow
(2) Brake arm
(3) Reference mark
(4) Brake panel
<REAR BRAKE>
(2)
(3)
(1)
(4)

Honda CRF150F Specifications

General

Engine Type	149cc air-cooled single-cylinder four-stroke
Bore and Stroke	57.3mm x 57.8mm
Compression Ratio	9.5:1
Ignition	CDI
Transmission	5-speed
Front Brake	Single disc
Rear Brake	Drum
Front Tire	70/100-19
Rear Tire	90/100-16
Starter	Electric
Ground Clearance	10.1 inches
Final Drive	Chain
Rear Suspension	Pro-Link single shock
Fuel Capacity	1.6 gallons
