Seat
#
Removal
1.
Remove the hook bolts and collars.
2.
Pull the seat back and up.
#
Installation
1.
Align the recess with the tab and insert
the prongs into the front stay and rear
stays.
2.
Install the collars onto the hook bolts.
Tighten the hook bolts.
Torque: 15 lbf·ft (21 N·m, 2.1 kgf·m)
20171129155157_31KZZA500_enu_BOOK Page 58 Wednesday, November 29 2017 16:14:18 JST
Removing & Installing Body Components u Seat
Maintenance
55
Hook bolt
Prongs
Hook bolt
Collar
Tab
Recess
Front stay
Seat
Rear stays
Collar
