Honda Dio 2020 User Manual

79
Maintenance
Brakes
u
Inspecting the Front Brake Pads
Inspecting the Front Brake
Pads
Check the condition of the brake pad wear
indicators.
The pads need to be replaced if a brake pad
is worn to the bottom of the indicator.
1. Inspect the brake pads from in front of
the brake caliper.
If necessary have the pads replaced by your
dealer.
Always replace both left and right brake pads
at the same time.
Brake pads
Disc
Wear
indicators
Wear
indicators
SCV125 II ID

Honda Dio 2020 Specifications

General

Displacement	109.51 cc
Max Torque	9 Nm @ 4750 rpm
Fuel Tank Capacity	5.3 liters
Kerb Weight	103 kg
Front Suspension	Telescopic
Front Brake	Drum
Rear Brake	Drum
Tyre Size (Front)	90/90-12
Wheelbase	1260 mm
Seat Height	765 mm
Transmission	Automatic
Frame Type	Underbone
Ground Clearance	160 mm
Fuel System	PGM-FI (Programmed Fuel Injection)
Starting Method	Electric Start
Tyre Size (Rear)	90/100-10
Engine Type	Air-cooled, 4-stroke, SI engine
Rear Suspension	Spring Loaded Hydraulic
