12
CONTROLS
ENGINE SWITCH
RECOIL STARTER
Key position:
OFF:
ON:
START:
OOFFFF
OONN
STARTER GRIP
ENGINE SWITCH
SSTTAARRTT
DDiirreeccttiioonn ttoo ppuullll
To start and stop the engine.
To stop the engine. Key can be removed/inserted.
To run the engine after starting.
To start the engine by operating the starter motor.
To start the engine, pull the starter grip lightly until resistance is felt,
and then pull briskly.
Return the key to the ON position once the engine has started. Do not
use the starter for more than 5 seconds at a time. If the engine fails to
start, release the switch and wait 10 seconds before operating the
starter again.
Do not allow the starter grip to snap back against the engine. Return it
gently to prevent damage to the starter.
