CYLINDER BLOCK
14-18
CRANKSHAFT
CRANKSHAFT BEARING
Install the 16 mm special nut (1) tightening the flywheel
to protect the crankshaft threads.
Pull out the radial ball bearing (2) using a commercially
available bearing puller (3).
Apply oil to the inner surface of the new bearing (4)
inner race (5).
Drive the radial ball bearing until it is fully seated on the
end using the special tools and hydraulic press.
EG3600CX/EG4000CX:
TOOLS:
Driver attachment, 30 mm I.D.
(6)
07746-0030300
Driver, 40 mm I.D. (7) 07746-0030100
Except EG3600CX/EG4000CX:
TOOLS:
Driver attachment, 35 mm I.D.
(6)
07746-0030400
Driver, 40 mm I.D. (7) 07746-0030100
(1)
(7)
(6)
(2)
(4)
(5)
(3)
