SERVICE INFORMATION
2-15
FUEL CUT SOLENOID SIDE:
GROUND CABLE (UH TYPE ONLY):
HARNESS BANDS
FUEL CUT SOLENOID WIRE
GROUND CABLE
GROUND TERMINAL
GROUND TERMINAL
Terminal
number
Wire color
G
G
Bl Black Br Brown
Y Yellow O Orange
Bu Blue Lb Light blue
G Green Lg Light green
R Red P Pink
W White Gr Gray
