SERVICE INFORMATION
2-16
GENERATOR SIDE (MH, RH, KH, UH, SH, SKH, RGH TYPE):
DC DIODE 4P
CONNECTOR
EXCITER WINDING
3P CONNECTOR
DC WINDING 3P
CONNECTOR
FIELD WINDING
WIRE CONNECTOR
FIELD WINDING
WIRE CONNECTOR
MAIN WINDING
TERMINAL
MAIN WINDING
TERMINAL
GROUND TERMINAL
MAIN WINDING
TERMINAL
MAIN WINDING
TERMINAL
Terminal
number
Wire color
1W/R
2Br
3Br
Terminal
number
Wire color
1W/R
2Br
3Br
MAIN WIRE
HARNESS SIDE
DC WINDING
SIDE
Terminal
number
Wire color
1Bu
2–
3Bu
Terminal
number
Wire color
1Bu
2–
3Bu
MAIN WIRE
HARNESS SIDE
EXCITER
WINDING SIDE
Terminal
number
Wire color
R
W
Terminal
number
Wire color
Br
Br
W
W
Terminal
number
Wire color
1Bl/R
2–
3Br
4Br
MAIN WIRE
HARNESS SIDE
Terminal
number
Wire color
Y/G
HARNESS BAND
CABLE TIE
HARNESS BAND
Bl Black Br Brown
Y Yellow O Orange
Bu Blue Lb Light blue
G Green Lg Light green
R Red P Pink
W White Gr Gray
