SERVICE INFORMATION
2-17
GENERATOR SIDE (RHH TYPE):
FIELD WINDING
WIRE CONNECTOR
FIELD WINDING
WIRE CONNECTOR
MAIN WINDING
TERMINAL
MAIN WINDING
TERMINAL
GROUND TERMINAL
MAIN WINDING
TERMINAL
MAIN WINDING
TERMINAL
Terminal
number
Wire color
1Bu
2–
3Bu
Terminal
number
Wire color
1Bu
2–
3Bu
MAIN WIRE
HARNESS SIDE
EXCITER
WINDING SIDE
Terminal
number
Wire color
R
W
Terminal
number
Wire color
Br
Br
W
W
Terminal
number
Wire color
Y/G
CABLE TIE
HARNESS BAND
Bl Black Br Brown
Y Yellow O Orange
Bu Blue Lb Light blue
G Green Lg Light green
R Red P Pink
W White Gr Gray
EXCITER WINDING
3P CONNECTOR
