MAINTENANCE
3-3
ENGINE OIL LEVEL CHECK
Place the engine on a level surface.
Remove the oil filler cap (1), and wipe the oil level
gauge (2) clean.
Insert the oil filler cap without screwing it into the oil filler
neck (3).
Remove the oil filler cap and check oil level shown on
the oil level gauge.
If the oil level is low, fill with recommended oil to the
upper level (4) of the oil filler neck.
SAE 10W - 30 is recommended for general use. Other
viscosities shown in the chart may be used when the
average temperature in your area is within the
recommended range.
Tighten the oil filler cap securely.
RECOMMENDED OIL:
SAE 10W-30 API service classification SE or later
(3)
(2)
(1)
(4)
(2)
(3)
(1)
SAE VISCOSITY GRADES
AMBIENT TEMPERATURE
