Reinstall the socket into the light
assembly by turning it clockwise
until it locks.
Place a cloth and insert a small
flat-tip screwdriver between the
left edge of the lens and the
housing. The lens will come down.
Testthelightstomakesurethe
new bulb is working.
When reinstalling the taillight
assembly, first place the two pins
in the holes in place. Tighten the
two mounting bolts.
Pull the bulb straight out of its
socket. Push the new bulb in until
it bottoms in the socket.
Turn on the parking lights and
check that the new bulb is
working.
Put the lens back into the light
assembly, right side first. Push on
the left edge until it snaps into
place.
1.
2.
6.
7.
3.
4.
5.
Lights
Replacing a Rear License Plate
Bulb
Maintenance
183
SCREWDRIVER
CLOTH
HOUSING
LENS
LENS
BULB
