Honda EU32i User Manual

SERVICING YOUR GENERATOR
59
SPARK ARRESTER SERVICE
If the engine has been running, the muffler will be very hot. Allow the muffler to
cool before servicing the spark arrester.
Clean the spark arrester as follows:
1. Remove the two 6×15 mm screws, and the rear cover.
Remove the two 6 mm screws, two 6×15 mm screws and the muffler
protector.
MUFFLER PROTECTOR
6 mm SCREWS
REAR COVER
6×15 mm SCREWS
6×15 mm SCREWS
6 mm SCREW 6×15 mm SCREW

Honda EU32i Specifications

General

Model	EU32i
Manufacturer	Honda
Category	Portable Generator
Rated Output	2600W
Maximum Output	3200W
Fuel Type	Gasoline
Starting Watts	3200W
Running Watts	2600W
Voltage	230V
Starting System	Recoil
Engine Type	4-stroke, OHV, single cylinder
Run Time at 1/4 Load	8.3 hours
