Honda Eu7000is User Manual

OPERATION
68
When operating generators in parallel operation, if one generator emits exhaust
toward the other, the CO-MINDER (CO Shut-off System) of the generator that is
receiving the exhaust may stop the engine. Pay attention to the following for
placing generators in parallel operation.
• Align the two generators so that their mufflers are on the same line and exhaust in
the same direction.
• Place the generator so that the muffler is pointed in the same direction as the
wind is blowing and the exhaust is directed away from buildings, other structures,
or vehicles.
EXHAUST
EXHAUST
ON THE SAME LINE
MUFFLER TIP
WIND DIRECTION
WIND DIRECTION
This generator may detect exhaust from
the adjacent generator and will stop the
engine.
OK INCORRECT
31Z376200.book 68 ページ ２０２０年２月１４日 金曜日 午前１０時３９分

Honda Eu7000is Specifications

General

Engine	Honda GX390 EFI
Fuel Type	Gasoline
Rated Power	5500W
Max Power	7000W
Dimensions	33.4" x 27.6" x 28.4"
Rated Voltage	120/240V
Rated Amperage	45.8/22.9A
Engine Displacement	389cc
Noise Level at 1/4 Load	52 dBA
Noise Level at Rated Load	58 dBA
Starting System	Electric
Run Time at 1/4 Load	18 hrs
Dry Weight	261 lbs
Outlets	1x 120/240V 30A Locking Plug
