Emergency Procedures Continued
16
Extricating Occupants
If you need to break windows, cut into the
body, or use “Jaws of Life”-type equipment
to remove occupants from a damaged vehicle,
be sure to stay within the cut zone (as
indicated on the illustration by the light blue
and dark blue diagonal lines). Do not cut into
the undercarriage or into the area containing
the capacitor module.
Cut Zone
High-Voltage
Cables
Fuel Cell
Module
Hydrogen
Tanks
Capacitor
Module
