Honda FF500 - Rotary Removal

48
Rotary removal:
RIGHT INNER ROTARY
RIGHT OUTER
ROTARY
FRONT
ROTARY SETTING
BOLT
RIGHT OUTER
ROTARY
LEFT INNER ROTARY
SPRING
WASHE R
RETAINING PIN (2)
KEY (2)
ROTARY PIN (2)
Remove the retaining pin and rotary pin, then remove the outer
rotary.
Remove the rotary setting bolt and spring washer, then remove the
inner rotary and key. Store the key not to lose it.
1.
2.
