Honda Forza NSS300 2013 User Manual

108
Specifications
Specifications
Specifications
■ Main Components
*1 Including rider, passenger, all luggage, and accessories
*2 Includes the weight of the luggage and added accessories.
Type NF-04
Overall length 2,165 mm (85.2 in)
Overall width
Except KO type 755 mm (29.7 in)
KO type 725 mm (28.5 in)
Overall height 1,185 mm (46.7 in)
Wheelbase 1,545 mm (60.8 in)
Minimum ground
clearance
135 mm (5.3 in)
Caster angle 27º 00´
Trail 89 mm (3.5 in)
Curb weight
NSS300 190 kg (419 lb)
NSS300A
Except KO type
KO type
192 kg (423 lb)
190 kg (419 lb)
Maximum weight
capacity
*1
Except KO type
KO type
177kg (390 lb)
157 kg (346 lb)
Maximum luggage
weight
*2
Luggage box 10 kg (22 lb)
Left fairing pocket 1.5 kg (3.0 lb)
Right fairing pocket 0.5 kg (1.0 lb)
Passenger capacity Rider and 1 passenger
Minimum turning
radius
2.4 m (7.9 ft)
Displacement 279 cm
3
(17.0 cu-in)
Bore × stroke 72.0 × 68.6 mm (2.8 × 2.7 in)
Compression ratio 10.5:1
Fuel
Unleaded petrol
Recommended: 91 RON or higher
Tank capacity 11.5 litres (3.04 US gal, 2.53 Imp gal)
Battery
YTZ12S
12V-11Ah (10 HR)/11.6Ah (20 HR)
FTZ12S
12V-10Ah (10 HR)/11.6Ah (20 HR)
Primary reduction CVT (2.350:1-0.800:1)
Final reduction 7.537

Honda Forza NSS300 2013 Specifications

General

Displacement	279 cc
Compression Ratio	10.5:1
Fuel System	PGM-FI electronic fuel injection
Ignition	Computer-controlled digital transistorized with electronic advance
Transmission	Automatic V-Matic belt drive
Front Tire	120/70-14
Rear Tire	140/70-13
ABS	Optional
Engine Type	Liquid-cooled, 4-stroke, single-cylinder
Front Suspension	33mm telescopic fork
Rear Suspension	Twin shock
Front Brake	Single 256 mm disc
Rear Brake	Single 240mm disc
Wheelbase	60.9 inches
Seat Height	28.2 inches
Width	29.7 inches
Curb Weight	192 kg (423 lbs)
