Honda Forza NSS300 2013 User Manual

28
Operation Guide
Switches
Start button
Headlight turns off when
operating the starter motor.
Horn button
Turn signal switch
u Pressing the switch turns the turn
signal off.
Headlight dimmer switch
• : High beam
• : Low beam
Engine stop switch
Should normally remain in the
RUN position.
u In an emergency, switch to the
OFF position (the starter
motor will not operate) to stop
the engine.
Passing light control switch
Flashes the high beam headlight.
Hazard switch
Switchable when the ignition
switch is ON. The signals don’t
continue flashing with the
ignition switch in OFF or LOCK.
Except U type

Honda Forza NSS300 2013 Specifications

General

Displacement	279 cc
Compression Ratio	10.5:1
Fuel System	PGM-FI electronic fuel injection
Ignition	Computer-controlled digital transistorized with electronic advance
Transmission	Automatic V-Matic belt drive
Front Tire	120/70-14
Rear Tire	140/70-13
ABS	Optional
Engine Type	Liquid-cooled, 4-stroke, single-cylinder
Front Suspension	33mm telescopic fork
Rear Suspension	Twin shock
Front Brake	Single 256 mm disc
Rear Brake	Single 240mm disc
Wheelbase	60.9 inches
Seat Height	28.2 inches
Width	29.7 inches
Curb Weight	192 kg (423 lbs)
