18
CONTROLS & FEATURES
Output Indicator
Overload Indicator
OUTPUT INDICATOR
(GREEN)
OVERLOAD INDICATOR
(RED)
The output indicator (green) is illuminated when the generator is
operating normally. It indicates that the generator is producing
electrical power at the receptacles.
If the generator is overloaded (in excess of 3.0 kVA), or if there is a
short circuit in a connected appliance, the overload indicator (red) will
come ON. The overload indicator (red) will stay ON, and after about
four seconds, current to the connected appliance(s) will shut off, and
the output indicator (green) will go OFF. However, the engine will
continue to run.
