7-4
RECOIL STARTER HRX217HYA • HRX217HZA
3. FAN COVER REMOVAL/INSTALLATION
Remove the top cover (P. 7 -2 ), and then reinstall the fuel tank cap to prevent dirt or debris from entering the fuel tank.
The recoil starter assembly does not need to be removed to remove the fan cover.
Reassembly is the reverse order of removal.
FAN COVER
6 x 23 mm BOLT* (5)
* CT type (cutting threads)

Honda HRX217K6HZA Specifications

General

Mulching	Yes
Bagging	Yes
Rear Discharge	Yes
Type	Walk-Behind
Starter	Recoil
Engine Type	Honda GCV200
Engine Displacement	200 cc
Cutting Width	21 inches
Drive Type	Self-propelled
Speed Range	0 to 4.0 mph
Fuel Capacity	0.25 gallons
