19. LIGHTS/METERS/SWITCHES
SERVICE INFORMATION
TROUBLESHOOTING
HEADLIGHT
INSTRUMENT CASE
TURN SIGNAL/TAIL LIGHT BULB
NEUTRAL SWITCH
FRONT BRAKE LIGHT SWITCH
19-1
19-2
19-3
19-4
19-5
19-5
19-6
REAR BRAKE LIGHT SWITCH
CLUTCH SWITCH
HANDLEBAR SWITCH
HORN
IGNITION SWITCH
THERMOSTATIC SWITCH
TEMPERATURE SENSOR
19-6
19-6
19-7
19-7
19-8
19-9
19-9
SERVICE INFORMATION
GENERAL
• Some wires have different colored bands around them near the connector. These are connected to other wires which have
the same color band.
• All plastic connectors have locking tabs that must be released before disconnecting, and must be aligned when
reconnecting.
• The following color codes used are indicated throughout this section and on the wiring diagram.
Bu = Blue
Bl = Black
Br = Brown
G = Green
Gr = Grey
Lb = Light Blue
Lg = Light Green
О = Orange
P = Pink
R = Red
W = White
Y = Yellow
To isolate an electrical failure, check the continuity of the electrical path through the part, A continuity check can usually
be made without removing the part from the motorcycle. Simply disconnect the wires and connect a continuity tester or
volt-ohmmeter to the terminals or connections.
A continuity tester is useful when checking to find out whether or not there is an electrical connection between the two
points. An ohmmeter is needed to measure the resistance of a circuit, such as when there is a specific coil resistance in-
volved, or when checking for high resistance caused by corroded connections.
TORQUE VALUES
Thermostatic switch
Ignition switch screw
Temperature sensor
TOOLS
Digital Muititester
or
Circuit tester (SANWA)
or
Circuit tester (KOWA)
18N-m<1.8kg-m, 13 ft-lb)
7 N-m (0.7 kg-m, 5 ft-lb)
10N-m (1.0 kg-m, 7 ft-lb) Apply sealant to the threads
07411 -0020000 or KS-AHM-32-003 (U.S.A. only)
07308-0020000
TH-5H
19-1
