The component parts in the engine
compartment are protected by the
cover. You may need to remove the
cover and the air intake cover when
you perform some simple
maintenance work.
To remove the front bulkhead cover
and the air intake cover, remove the
holding clips with a flat-tip
screwdriver.
Covers are secured by holding clips.
Engine Compartment Covers
Maintenance
471
FRONT BULKHEAD COVER
HOLDING CLIP
AIR INTAKE COVER
