Turn the dial at the bottom of the
jack clockwise until the top of the
jack contacts the jacking point.
Make sure the jacking point tab is
restinginthejacknotch.
Attach the stay to the extension,
then attach the wheel nut wrench
to the end of the extension.
Insert the hook at the end of the
stay into the opening on the dial at
the bottom of the jack.
Make sure the stay, the extension,
and the wheel nut wrench are
securely attached.
13. 14. 15.
Changing a Flat Tire
512
DIAL
CONNECTOR BUTTON
DIAL
HOOK
STAY
CONNECTOR BUTTON
EXTENSION
WHEEL NUT WRENCH
