Inspecting the Brake Pads
Check the condition of the brake pad wear
indicators.
Front
The pads need to be replaced if a
brake pad is worn to the indicator.
Rear
The pads need to be replaced if a brake
pad is worn to the bottom of the indicator.
1.
Front
Inspect the brake pads from the
bottom of the brake caliper.
2.
Rear
Inspect the brake pads from the rear
right of the vehicle.
If necessary, have the pads replaced by your
dealer.
Always replace both left and right brake pads
at the same time.
Brakes u Inspecting the Brake Pads
Maintenance
64
Disc
Pad Pad
Wear indicators
Disc
Pad
Pad
Wear indicators
Front Rear
