Blown Fuse
Before handling fuses, see “Inspecting and
Replacing Fuses.” 2 P. 47
#
Fuse Box Fuses
1.
Remove the battery lid. 2 P. 57
2.
Remove the fuse box A.
3.
Remove the battery cover.
2 P. 55
4.
Remove the fuse box B from the battery cover.
5.
Open the fuse boxes cover.
6.
Pull the fuses out one by one with the
fuse puller in the tool kit and check for a
blown fuse. Always replace a blown fuse
with a spare fuse of the same rating.
7.
Install the parts in reverse order of removal.
NOTICE
If a fuse fails repeatedly, you likely have an
electrical problem. Have your vehicle inspected
by your dealer.
20210315181452_31K2EA000_enu_BOOK Page 79 Monday, March 15 2021 18:17:29 JST
Electrical Trouble u Blown Fuse
Troubleshooting
76
Spare fuseFuse box A
Fuse box B
Spare fuses
Battery cover
To Next Page
