(1)
(2)
LEFT HANDLEBAR
(1) reverse selector knob
(3)
(3) downshift switch
(2) rear brake lever/
parking brake lever
31
Reverse Selector Knob
Controls & Features
Instruments & Controls
Riding in Reverse,
The reverse selector knob ( ), located on the rear brake lever/parking
brake lever ( ), is used to shift into reverse. To operate, with your ATV
stopped and the transmission in neutral (make sure the gear position
indicator shows ‘‘N’’), push in the knob, squeeze the rear brake lever/
parking brake lever, then press the downshift switch ( ) once. See
page .
1
3
2
68
０９／０５／１１ １４：４６：１３ ３１ＨＰ４８３０ ００４０
