Honda XR250R User Manual

AIR CLEANER
The air cleaner should be serviced at regular
intervals (page 45). When riding in dusty
areas, more frequent service may be
necessary.
1. Remove the air cleaner cover screws (1)
and the cover (2).
2. Remove the wing nut (3).
3. 3. Remove the air cleaner element (4).
(1) Screws (2) Air cleaner cover
4. Wash the element in clean non-flammable
or high flash point solvent and dry it
thoroughly.
 Never use gasoline or low flash point
solvents for cleaning the air cleaner
element. A fire or explosion could result.
5. Soak the element in clean gear oil (SAE80-
90) until saturated, then squeeze out the
excess oil.
6. Install the element, and install the air cleaner
cover.
(3) Wing nut (4) Air cleaner element
50

Honda XR250R Specifications

General

Displacement	249 cc
Bore x Stroke	73.0 mm x 59.5 mm
Compression Ratio	9.3:1
Fuel System	Carburetor
Ignition	CDI
Transmission	5-speed
Final Drive	Chain
Front Suspension	Telescopic fork
Rear Suspension	Pro-Link single shock
Front Brake	Single disc
Rear Brake	Drum
Front Tire	80/100-21
Engine Type	Air-cooled, four-stroke, single-cylinder
Fuel Capacity	9.5 liters (2.5 US gal)
