Honeywell Home D15S User Manual

GB
2 MU0H-1049 GE23 R0919
1 Safety Guidelines
1. Follow the installation instructions.
2. Use the appliance
• according to its intended use
• in good condition
• with due regard to safety and risk of danger.
3. Note that the appliance is exclusively for use in the
applications detailed in these installation instructions
(see 2 Technical Data). Any other use will not be
considered to comply with requirements and would
invalidate the warranty.
4. Please take note that any assembly, commissioning,
servicing and adjustment work may only be carried
out by authorized persons.
5. Immediately rectify any malfunctions which may
influence safety.
2 Technical Data
2.1 D15S
2.2 D15SN
2.3 D15SH
2.4 D15SI
3 Options
For Options visit homecomfort.resideo.com/europe
Media
Medium: Drinking water
Connections/Sizes
Connection sizes: 2", 2
1
/
2
", 3", 4", 6", 8"
Nominal sizes: DN50, DN65, DN80, DN100,
DN150, DN200
DN125 available with adapter
flanges DN100/DN125
Pressure values
Max. inlet pressure: 16 bar
Outlet pressure: DN 50 - 100: 1.5 - 7.5 bar
DN 150 - 200: 1.5 - 8 bar
Nominal pressure: PN16
Min. pressure drop: 1.0 bar
Operating temperatures
Max. operating temperature
medium:
65 °C
(WRAS approved up to 23°C)
Media
Medium: Drinking water
Connections/Sizes
Connection sizes: 2"- 4"
Nominal sizes: DN50 - DN100
Pressure values
Max. inlet pressure: 16 bar
Outlet pressure: 0.5 - 2 bar
Nominal pressure: PN 16
Min. pressure drop: 1 bar
Operating temperatures
Max. operating temperature
medium:
65 °C
Media
Medium: Drinking water
Connections/Sizes
Connection sizes: 2" - 4"
Nominal sizes: DN50 - DN100
Pressure values
Max. inlet pressure: 25 bar
Outlet pressure: 3.0 - 10 bar
Nominal pressure: PN25
Min. pressure drop: 1 bar
Operating temperatures
Max. operating temperature
medium:
65 °C
Media
Medium: Drinking water
Connections/Sizes
Connection sizes: 2
1
/
2
", 3", 4"
Nominal sizes: DN65, DN80, DN100
Pressure values
Max. inlet pressure: 16 bar
Outlet pressure: 1.5 - 6.5 bar
Nominal pressure: PN16
Min. pressure drop: 1.0 bar
Operating temperatures
Max. operating temperature
medium:
65 °C
