SPECIFICATIONS
F100 Specications
MERV Rating*:
Static Pressure Drop:
Efciency Denition*:
 = 32%
= 72%
 = 96%
0
500 1000 1500
2000
0.000
0.050
0.100
0.150
0.200
0.250
0.300
12.5 X 20
16 X 20
16 X 25
20 X 20
20 X 25
FILTER SIZE
PRESSURE DROP (IN. WC)
AIRFLOW (CFM)
M34911
WHEN FIRST INSTALLED. PRESSURE DROP INCREASES AS FILTER
BECOMES LOADED. REPLACE FILTER WHEN PRESSURE DROP
REACHES 0.5 IN. WC. (0.1 kPa).
AVAILABLE ONLY IN UNITED STATES.
2
1
1
2
F200 Specications
MERV Rating*:
Static Pressure Drop:
Efciency Denition*:
 = 63%
= 91%
 = 99%
0
500 1000 1500
200
0
0
0.1
0.2
0.3
0.4
PRESSURE DROP (IN. WC)
AIRFLOW (CFM)
M13662
WHEN FIRST INSTALLED. PRESSURE DROP INCREASES AS FILTER
BECOMES LOADED. REPLACE FILTER WHEN PRESSURE DROP
REACHES 0.5 IN. WC. (0.1 kPa).
1
1
20 x 25 in.
(508 x 635 mm)
20 x 20 in.
(508 x 508 mm)
16 x 25 in.
(406 x 635 mm)
16 x 20 in.
(406 x 508 mm)
M37054A
F100F SIZE
IN.
16 X 25
16 X 20
20 X 25
20 X 20
25 X 20
25 X 22
MM
406 X 635
406 X 508
508 X 635
508 X 508
635 X 508
635 X 559
DIM. A
14-1/4
14-1/4
18-1/4
18-1/4
23-1/8
23-1/8
362
362
464
464
587
587
DIM. B
16-1/4
16-1/4
20-3/16
20-3/16
25-3/16
25-3/16
413
413
513
513
640
640
23-1/4
18-1/4
23-1/4
18-1/4
18-1/4
20-1/4
DIM. C
591
457
591
457
457
514
DIM. D
25-7/16
20-7/16
25-7/16
20-7/16
20-3/4
22-3/4
646
519
646
519
527
578
IN. MM IN. MM
IN. MM IN.
MM
6-3/4
(170)
1-7/16 (37)
DIM. A
(SEE
TABLE)
1
(25)
DIM. C (SEE TABLE)
DIM. D (SEE TABLE)
DIM.
B
(SEE
TA
BLE)
Dimensions
Temperature Rating

Approvals
Underwriters Laboratories, Inc.:








Replacement Air Filters
Filter Size (in.)
Part Number
F100 - MERV 11 F200 - MERV 13
16 x 20 FC100A1003 FC200E1003
16 x 25 FC100A1029 FC200E1029
20 x 12.5 FC100A1052 N/A
20 x 20 FC100A1011 FC200E1011
20 x 25 FC100A1037 FC200E1037
21.5 x 27.5 FC100A1045 N/A
25 x 20
FC100A1037 FC200E1037
25 x 22
FC100A1037 FC200E1037
Media Air Cleaner 68-0239EF—13 

Honeywell Home F100F Specifications

General

Brand	Honeywell Home
Model	F100F
Category	Air Cleaner
Language	English
