Web Client Operation
213
Port Enter the Port number for the server.
Username Enter the user name for logging into the server.
Password Enter the password for logging into the server.
Anonymous Click to enable/disable anonymously logging into the server.
Remote Directory
When the remote directory is null, the NVR automatically creates
folders according to the IP, time, and channel.
File Size
Here you determine the size of the upload file. If the setup file size is
larger than the actual file, then the system uploads the entire file. If the
setup file size is smaller than the actual file, then the system uploads
only the set file size. If you enter 0 here, then the system uploads all
corresponding files.
Image Upload
Interval
This is the interval that the CVR waits through before uploading an
image to the FTP site. Select from 0 to 3600 seconds. 0 means that
there is no interval.
Channel Select a channel.
Weekday Select a weekday.
Time Periods You can configure up to two time periods per channel.
Recording Type Select from Alarm&IVS&POS, MD, or Regular.
Click FTP Test to test the FTP connection. A popup window shows the status of the
connection.
Configuring Manual Recording Storage Settings
Click Record under Storage to open the Record configuration interface. The Record settings
can be different for the Main Stream, Sub Streams and Snapshot recordings.
Figure 12-86 Manual Recording Storage Interface
