Honeywell HPA200 series Manual

2 3
HPA100 series, HPA200 series, HPA300 series
Type
R
A
A
R
Odor Reducing Pre-filter
Front Grille
YOUR AIR PURIFIER
SETUP
• Select a firm, level and flat location.
• When operating, large volumes of air are drawn toward the air purifier. Surrounding areas should be cleaned
and/or vacuumed frequently to prevent build-up of dust and other contaminants. This may also help prolong
the life of the filter. If the unit is placed on a light colored carpet, a small mat or rug should be used underneath
to prevent staining. This is especially important in homes with contamination from smoking, fireplaces, or
where candles are burned.
• Ensure the front of the unit faces away from the closest wall or furniture.
• Ensure no grilles are blocked.
Control Panel
HPA090 series
Type
R
A
A
R
True HEPA
Filter (1)
Type
R
A
A
R
Odor Reducing
Pre-filter
Front Grille
The True HEPA Filters and Odor Reducing Pre-filter are supplied within the air purifier. New air purifiers have their
filters wrapped to ensure purity, and are labeled to help identify the proper replacement filter. (
Type
R
A
A
R
True HEPA
Filter; Type
R
A
A
R
Odor Reducing Pre-filter)
• Before using your new air purifier you must remove the wrappers covering the filters and pre-filter. Make sure
the air purifier is OFF and unplugged. Press the two hand symbols (
) on the front grille to release it from the
unit and pull the grille toward you to remove it (see Fig. 2). Grasp the sides of the filter frame near its top end
and pull outward. Repeat for the second and third filter if applicable.
• Remove protective wrap from the filters (including the pre-filter) that have been
supplied with your air purifier.
• Place the HEPA filter(s) into the air purifier housing. Ensure that the removal “pull”
tabs are facing outward (this will facilitate filter removal later). Place the pre-filter
on top of the HEPA filter(s). Tuck the edges of the pre-filter into the tabs that are
located around the edges of where the HEPA filter(s) are inserted.
Model HPA300 has velcro strips on the housing where the pre-filter should
be attached.
• Replace the front grille by placing the tabs on the bottom of the grille into the
slot(s) on the unit. Gently push the top of the grille into place by pressing on the
hand symbols (
) to secure in place.
Control Panel
Type
R
A
A
R
True HEPA Filters
HPA100 HPA300HPA200
HOW YOUR AIR PURIFIER WORKS
This model air purifier incorporates a 2-stage cleaning system
to help clean the air that passes through the
filter in the unit (Fig. 1).
Stage 1: Odor Reducing Pre-filter
Stage 2: True HEPA Filter that captures
particles as small as 0.3 microns or larger
2
Filter(s)
Odor Reducing
Pre-filter
STAGE 1
STAGE 2
Fig. 1
INSTALL TRUE HEPA FILTERS AND ODOR REDUCING PREFILTER
Fig. 2
OPERATION
This product earned the ENERGY STAR
®
rating by meeting strict energy efficiency guidelines set by the
U.S. EPA. The U.S. EPA does not endorse any manufacturer claims of healthier indoor air from the use
of this product.
Portable air purifiers are more effective in rooms where all doors and windows are closed. It is recommended that
you run your air purifier while you are at home to help clean the air.
HPA090 Series Operation:
• Once the filters have been unwrapped and replaced in the unit, ensure the air
purifier’s control knob is turned to the OFF position and plug the power cord
into a working electrical outlet.
• Select the desired cleaning level by turning the knob to General Clean, Allergen
or Turbo setting (Fig. 3).
Fig. 3 HPA090 Control Panel

Honeywell HPA200 series Specifications

General

Room Size	310 sq. ft.
CADR Smoke	200
Fan Speeds	4
Filtration Stages	2
Pre-filter	Yes
Control Type	Electronic
Oscillation	No
Filter Change Indicator	Yes
Product Type	Air Purifier
Model	HPA200
HEPA Filter Efficiency	99.97%
Air Changes per Hour (ACH)	5
Warranty	5 years
Filter Type	HEPA
