Honeywell MP953 Series

POSITIONER RETROFIT AND
SPRING KITS
Table 12. MP953 Positive Positioner Retrofit Kits.
Part No. 1
Description*
14004138-001 For RA valve actuators (Fig 12)
14004139-001 For 8- and 13-in. (203- and 330-mm),
1 3/4-in. (19-mm) stroke valve
actuators (Fig. 13)
14004140-001 For 8- and 13-in. (203- and 330-mm),
1 l-1/2 in. (38-mm) stroke valve
actuators (Fig. 14)
14004214-001 For 5-in. (127-mm), 3/4-in. (19-mm)
stroke valve actuators (Fig. 13).
I
(Positioner has cream-colored lower
plate.)
Table 13. MP953 Feedback Spring Kits.
Part No.
Description*
1400421 l-001 For
3/4-in. (19-mm) stroke DA vahs
14004212-001~
For l-l/&in. (38-mm) stroke DA
14004213-001
I
* All kits include springs with 3-, 5, and lo-psi (21-,
For RA valve actuators (includes bias
34-, and
69-kPa) range.
spfiw~
* Includes corresponding feedback spring kit listed in
Table 13.
Fig. 12. Positive Positioner Retrofit Kit 14004138-001.
