Camera Function
② PZM display
: Set ON/OFF for each PZM Zone.
CONTROL OFF → ON
③ PZM Horizontal center starting point
: Set PZM for the starting point of Horizontal center.
H SIZE 60 ~ 496
④ PZM Vertical center starting point
: Set PZM for the starting point of vertical center.
V SIZE 24 ~ 198
⑤ Moving PZM area
: Configured PZM area can be moved by this menu.
If you press MENU button at MOVE CONTROL, below
screen will appear. You can move PZM area by Joystick
of
the controller. To exit MOVE CONTROL
menu, press ESC button.
< PZM position move >
<< PZM MODE >>
ZONE NUMBER
DISPLAY
H SIZE
V SIZE
MOVE CONTROL
COLOR
ALPHA
RETURN
1
ON
60
24
BLUE
1
7-5. PRIVACY ZONE
① Set Privacy ZONE
: PZM(Privacy Zone Mask) is to hide the unwanted view to
protect privacy invasion. It works with Zoom/PAN/TILT
operation. Select PZM zone up to 8 zones.
ZONE NUMBER 1 → 2 → …. → 8
< PZM MODE change >
⑥ PZM Masking
: Choose the Color to mask the PZM zone. 8 color
(Black, Gray, Light Gray, White, Red, Blue, Green, Yellow)
is available.
PZM MASKING BLUE → RED → …. → GREEN
⑦ Transparency of PZM area
: Transparency of PZM area can be decided
ALPHA 1 ~ 15
7-6. NIGHTSHOT MODE
① NIGHTSHOT MODE
: It is used in low illumination condition. ON is Night mode,
OFF is normal state. Sensitivity of camera becomes more
higher level like BW camera.
external IR illuminator can be available when AUTO
mode is converted ON / OFF automatically according to
illuminance change.
MODE OFF → ON → AUTO
② NIGHTSHOT MODE DETECT TIME
: Set time to protect susceptible conversion of ON/OFF
according to illuminance change on Auto. When illuminace
keeps the state during detect time, convert ON/OFF.
DETECT TIME 1 → 2 → …. → 10
③ NIGHTSHOT DETECT MODE
: It is useful with external IR illuminator set on Auto. Select
CDS sensor ON/OFF to detect the illuminance state more
effectively.
DETECT MODE BRT → CDS → ALL
☞ caution
BRT means shooting scene brightness, CDS sensor’s
operation
depends on circumstantial brightness. Select to match with
installation
circumstance.
<< NIGHTSHOT MODE >>
MODE
DETECT TIME
SENSING
D- >N LEVEL
N- >D LEVEL
NIGHT COLOR
RETURN
OFF
5
BRT
1
4
B/W
< NIGHTSHOT MODE >
ENG
To Next Page
