IDR-2P, -2A & -6A Repeaters User Manual
Appendix 1 - Specification
A1 - 2997-411-000-9, Issue 9
March 2008
RS232 Serial Port - Temporary PC connection
Baud rate: 9600 Baud
Connector: D-type on Control Board
Max cable length: 5m
RS232 Isolated Serial Port (Optional) - Notifier-approved Equipment
Isolation: Functional at 42V
Baud rate: 9600 Baud
Connector: Terminal block on RS232 Board
Max cable length: 15m
Display and Indications:
Alphanumeric Display: IDR-2A & 2P use 2 x 40 character LCD
IDR-6A uses 64x240 pixel LCD
(arranged to give 6 lines of characters)
LED Indicators: General FIRE and FAULT,
DISABLEMENT, POWER, PRE-
ALARM, TEST, DELAY ACTIVE, SYSTEM
FAULT, and COMMUNICATIONS LOSS
Controls
Pushbuttons - 2A (ID50): MUTE BUZZER, END DELAY/
EVACUATE, SILENCE/RESOUND,
RESET
Pushbuttons - 2A (other): MUTE BUZZER, ACCEPT, EVACUATE,
SILENCE SOUNDERS, RESOUND
SOUNDERS, RESET
Pushbuttons - 6A: MUTE BUZZER, END DELAY/
EVACUATE, SILENCE/RESOUND,
CHANGE TABS, ZONES IN ALARM,
RESET
Keypad - 2P/2A/6A , , , and
Buzzer
In order of decreasing priority:
Fire: Continuous pulses
Pre-alarm: 3 pulses every 12 seconds
Fault: Continuous tone
Fire (accepted): 3 pulses every 12 seconds
Pre-alarm (accepted): 3 pulses every 12 seconds
Fault (accepted) 1 pulse every 2 minutes
Disablement 1 pulse every 2 minutes
