Hoonved HD BT - Control Panel

35
CONTROL PANEL
TANK temperature led light
TANK
Temperature Display
BOILER
Temperature Display
LONG cycle led light
MEDIUM cycle led light
SHORT cycle led light
CHECK led light
P3
P2
S3
S9
LC3
LC2
LC1
LTV
LRCK
Q1
START CYCLE Button
CYCLE Selection Button
ON/OFF Switch
HD 40 BT-HD 60 BT
HD 80 BT-HD 130 BT
LB 56 BT-LB 67 BT
LB 83 BT-LB 134 BT
Fig. 1
