Hoover CH83000 - Page 9

Drawing# Item ID Item Description Qty Needed
1 . SP-3-ST-BLK Black 3 Gal.Solution Tank 1.00
2 . SP-3-RT-BLK Black 3 Gal. Recovery Tank 1.00
3 . 10-0383 6-32 x 1/4 Phil Pan Screw 6.00
4 . 10-0400-D Latch for Sniper 1.00
5 . 10-0412 C-Channel for Spotter Handle 2.00
6 . 10-0414 Rivet for Spotter Handle 4.00
7 . 10-0384 .125 Thick Nylon Washer 4.00
8 . 10-0385 .06 Thick Nylon Washer 4.00
9 . 10-0074 Flat Washer #8 SAE 5.00
10 . 10-0216 Allen Head Screw for Backpack 4.00
11 . 10-0379 8-32 x 3/8 Screw 4.00
12 . 10-0405 1 1/2" PVC SCH40 Slip Thread 1.00
13 . 10-0302-A Hatch Cover Gasket for Spotter 1.00
14 . 10-0416-A 1-1/2" Black ABS Stand Pipe 0.60
15 . 10-0304 Spotter Cap & Float Assembly 1.00
16 . 10-0419 Screw for Spotter Hatch 6.00
17 . SP-3-H-ORA-1 3 Gallon Spotter Orange Handle 1.00
18 . 10-0406 Nylon Barb 90 1/8" NPT 1/4" 2.00
19 . 80-0017-2 Bulk Head fitting for Spotter 1.00
20 . 10-0403 1/8" Brass Female Coupler 1.00
21 . 10-0402 1/8" Male QD 1.00
22 . 10-0434 Threaded Hose for Spotter 2.50
23 . 10-0407 1/8" Strait Nylon Barb NPT 4.00
24 . 10-0845-2 1/8" Strainer for Spotter 1.00
25 . 10-0300 55 psi Pump for Spotter 1.00
26 . 10-0301 L Bracket for Spotter 1.00
27 . 10-0435 Oetiker Clamp 4.00
28 . 10-0303 Roller Blade Wheel for Spotter 2.00
29 . 10-0387 5/16 x 1in Spotter Wheel Bolt 2.00
30 . 10-0022 Shoulder & Waist Belt Screw 1.00
31 . 10-0017 Deflector Screw 1.00
32 . 10-1028 Bottom Base Plate for Spotter 1.00
33 . 10-0492 Screw for Plates on Spotter 2.00
34 . 10-0014 Motor Screw 2.00
35 . 10-0380 10-32 x 3/8" Screw 2.00
36 . 10-1024 Motor Mount Plate for Spotter 1.00
37 . 10-0354 3 Gallon Spotter Motor 1.00
38 . 10-0386 Stamped Motor Screen 1.00
39 . 10-1030 Spotter Motor Gasket 1.00
40 . 10-0027-A Strain Relief Nut 1.00
41 . 10-1026 Switch Plate for 3 Gal. w/Heat 1.00
42 . 10-0027 Pigtail Strain Relief 1.00
43 . 10-0448 20 ft. Spotter/Air Mover Cord 1.00
44 . 10-0025 On/Off Switch 2.00
45 . 10-0400-C Keeper Latch for Sniper 1.00
™
