Carton contents
Remove all parts from carton and
identify each item shown.
Make sure all parts are located before
disposing of packing materials.
A
B
C
E
D
F
A
B
C
D
If you need any assistance:
Visit our website at www.hoover.com. Click on the “Service” button to find the service outlet
nearest you OR
Call 1-800-944-9200 for an automated referral of authorized service outlet locations (U.S. only) OR
Call 1-330-499-9499 to speak with a representative in our Consumer Response Center.
Please do not return this product to the store.
Continued
➜
Assembling cleanerDi
Attach handle
Slide handle section (A) onto back
of handle.
1-2
1-3
1-4
1-5
1-6
1-7
1-1
A. Handle section and screw (taped
to handle)
B. Cleaner body
C. Cleaning tools
D. Hose
Place combination tool (D) into
opening on back of handle.
The crevice wand (E) slides over the
post (F) on the back of the cleaner.
Position tools
The holder (B) for the powered hand
tool snaps onto the tabs on the front
of the handle. Be sure the holder is
properly positioned as shown in
the drawing.
Push screw into hole on back of
handle. Tighten screw securely with
a Phillips screwdriver.
Place the powered hand tool (C)
into the holder as shown.
Position hose
Align end of hose with projections
over slots in dirt duct on back of
cleaner. Twist to lock in place.
The hose connector allows the hose
to swivel.
