Drawing# Item ID Item Description Qty Needed
1 . SP-3-ST-BLK Black 3 Gal.Sol. Tank 1.00
2 . SP-3-RT-BLK Black 3 Gal. Rec. Tank 1.00
3 . 10-0383 6-32 x 1/4 Phil Pan Screw 6.00
4 . 10-0400-D Latch for Sniper 1.00
5 . 10-0412 C-Channel for Spotter Handle 2.00
6 . 10-0414 Rivet for Spotter Handle 4.00
7 . 10-0384 .125 Thick Nylon Washer 4.00
8 . 10-0385 .06 Thick Nylon Washer 4.00
9 . 10-0074 Flat Washer #8 SAE 11.00
10 . 10-0216 Allen Head Screw for Backpack 4.00
11 . 10-0379 8-32 x 3/8 Screw 4.00
12 . 10-0405 1 1/2" PVC SCH40 Slip Thread 1.00
13 . 10-0302-A Hatch Cover Gasket for Spotter 1.00
14 . 10-0416-A 1-1/2" Black ABS Stand Pipe 1.00
15 . 10-0304 Spotter Cap & Float Assembly 1.00
16 . 10-0419 Screw for Spotter Hatch 6.00
17 . SP-3-HS-BLK Black 3 Gal. HeatSkirt 1.00
18 . 10-0831 S/R Bracket for Sniper 1.00
19 . 10-0832 S/R Strap Bolts 2.00
20 . 10-0300 55 psi Pump for Spotter 1.00
21 . 10-0403-M 1/8" Brass Male Nipple 1.00
22 . 10-0901 175psi Relief Valve for Heater 1.00
23 . 10-0510 1/8" Brass Plug 1.00
24 . 80-0017 Bulk Head fitting for Sniper 2.00
25 . 80-0024-B !MPT x 3/8 Barb 4.00
26 . 10-0826 3/4" Hose Clamp for Sniper 6.00
27 . 10-0843 3/8" Black Hose for Sniper 1.00
28 . 10-0434 Threaded Hose for Spotter 1.00
29 . 10-0407 1/8" Strait Nylon Barb NPT 2.00
30 . 10-0845-2 1/8" Strainer for Spotter 1.00
31 . 10-0301 L Bracket for Spotter 1.00
32 . 10-0828 90 Brass Fitting for Sniper 1.00
33 . 10-0022 Shoulder & Waist Belt Screw 3.00
34 . 10-0017 Deflector Screw 1.00
35 . T-C-011 Female Terminal Conector
36 . T-WPUR Purple Wire
37 . 80-0011-2 90 Deg. Street Elbow 1.00
38 . 80-0010 1/4" Brass Tee 1.00
39 . 10-0843 3/8" Black Hose for Sniper 1.00
40 . 10-0852 1/4" 90 Degree Brass Elbow 1.00
41 . 80-0101-M 1/4" Male Check Valve 1.00
42 . 80-0014 3/8" B x 1/4" F 90 Deg. 1.00
43 . 10-0479 1/4" Male Close Nipple 1.00
44 . 10-0870 1/4" Male QD 1.00
45 . 10-1500-B Heater Element 600 Watt 1.00
46 . 10-0814 Senor for Sniper Heater 1.00
47 . 10-0814-B Manual Sensor for Heater 1.00
48 . 10-0907 Strain Relief for Tube Heater 1.00
49 . 10-0906 Box for Tubular Heater 1.00
50 . 10-0900 Heater Body Tubular 1.00
51 . 10-0801-G PipeWrap Insulation for Heater 1.00
52 . SP-3-H-ORA-1 3 Gallon Spotter Orange Handle 1.00
53 . 10-0387 5/16 x 1in Spotter Wheel Bolt 2.00
54 . 10-0303 Roller Blade Wheel for Spotter 2.00
55 . 10-0822 Exhaust Grate for Sniper 2.00
56 . 10-0419-A Screw for Sniper Hatch 2.00
57 . 10-0014 Motor Screw 2.00
58 . 10-0380 10-32 x 3/8" Screw 2.00
59 . 10-1024 Motor Mount Plate for Spotter 1.00
60 . 10-0354 3 Gallon Spotter Motor 1.00
61 . 10-0386 Stamped Motor Screen 1.00
63 . 10-1030 Spotter Motor Gasket 1.00
64 . 10-0027-A Strain Relief Nut 1.00
65 . T-WBLA Black Wire
65 . 10-0027 Pigtail Strain Relief 1.00
66 . 10-0448 20 ft. Spotter/Air Mover Cord 1.00
67 . 10-0025 On/Off Switch 3.00
68 . 10-1026 Switch Plate for 3 Gal. w/Heat 1.00
69 . 10-0400-C Keeper Latch for Sniper 1.00
70 . 80-0022-A Screw for 500psi Panel 2.00
71 . 10-0204 Motor Mount Back-Up Washer 2.00
