Hoover Wind Tunnel - Page 7

Reposition bag door by placing
tabs on bottom of door into
opening. Press top of door to snap
s e c u r ely shut.
Should you want to replace the cloth
filter bag, ask for Hoover part
No. 43667-050.
Hold filter bag as shown in
Fig. 28 aligning opening in bag
with (B). Push (A) firmly onto (B). Fit
bottom of filter bag into bag compart-
m e n t .
After replacing clip, open bag
cap (C).
To replace filter bag clip, first
fold down top of bag over
plastic strip (D).
Push clip over edge.
Empty filter bag over paper,
shaking bag until clean.
Slide filter bag clip from bottom
of bag.
Snap cap (C) into collar open-
ing.
Grasp filter bag collar (A) and
pull collar from tube (B).
How to empty
Push down at top of bag door
and pull forw a rd. Remove door.
