should be used only until a pro p e r l y
g r ounded outlet (B) can be installed by a
qualified electrician. The green colore d
rigid ear, lug, or the like (F) extending fro m
the adapter must be connected to a per-
manent ground (G) such as a pro p e r l y
g r ounded outlet box cover. Whenever the
adapter is used, it must be held in place
by a metal scre w.
Note: In Canada, the use of a tempo-
rary adapter is not permitted by the
Canadian Electrical Code.
electrician or service person if you are in
doubt as to whether the outlet is pro p e r l y
g r ounded. Do not modify the plug pro v i d -
ed with the appliance - if it will not fit the
outlet have a proper outlet installed by a
qualified electrician. This appliance is for
use on a nominal 120 volt circuit and has a
g r ounding plug that looks like the plug
illustrated in sketch (A).
A temporary adapter (D) may be
used to connect this plug to a 2-pole
receptacle (E) if a pro p e r ty grounded outlet
is not available. The temporary adapter
4
1 2
1 3
1 4
1 4
Cleaner description
How to use
The assembled cleaner will
look like the drawing.
1. Handle
2. Cord hooks: wrap cord around
hooks for storage. The top hook can
be rotated right or left for easy cord
release.
3. Hose
4. ON/OFF Switch: located on left
rear corner of cleaner body.
5. Carrying handle
6. Bag door
7. Stair cleaning handle: located
on lower edge of bag door.
8. Handle release lever: step on
lever to lower to operating or low
positions.
9. Headlight
10. Nozzle control knob: slide
knob to correct setting for height of
carpet being cleaned.
11. Furniture guard: helps prevent
cleaner from marking furniture.
12. Edge groomers
13. Wands
14. Final exhaust filter
15. Dusting brush
16. Crevice tool
17. Furniture nozzle
18. Hose hook
1
2
2
2
3
4
4
5
6
7
8
9
1 0
11
1 2
1 3
1 7
1 8
1 4
1 5
1 6
Operate cleaner only at voltage
specified on data plate on bottom
of cleaner.
WARNING: Electric shock could
occur if used outdoors or on wet
surfaces
G r ounding instru c t i o n s
This appliance must be grounded. If
it should malfunction or bre a k d o w n ,
g r ounding provides a path of least
resistance for electrical current to re d u c e
the risk of electric shock. This appliance is
equipped with a cord having an equip-
m e n t - g rounding conductor (C) and
g r ounding plug (A). The plug must be
plugged into an appropriate outlet (B) that
is properly installed and grounded in
a c c o r dance with all local codes and ord i -
n a n c e s .
DANGER –
I m p r oper connection of the equipment-
g r ounding conductor can result in the risk
of electric shock. Check with a qualified
C
F
G
A
B
D
E
1 3
1 3
1 2
8
To Next Page
