4
Plug and play,no configuration required, easy to use.
1.3 product specification
Hardware Specifications
Chipset
RealtekHigh Performance Chipset
Flash
16MB
RAM
128DDR
Port
8 10/100/1000Mbps RJ45 ports
2 Gigabit SFP fiber ports
1 Console port
PoE
8 10/100/1000Mbps RJ45 port support
PoE
Max 150W
Single port max 46W
LEDs
10 Link/Act LEDs
8 POE LEDs
1 Power LEDs 1 SYS LED
Performance
Forwarding mode: store and forward
Switch Volume (Full-duplex) :20Gbps
Packet forwarding rate:14.88Mpps
8K MAC address table
lightning protection
±4KV
ESD
No barrier: ±6KV Air:±8KV
Input
100-240V/50-60Hz
Dimension
(L×W×H)
285mm×180mm×44mm
