PARTS LIST
TROUBLESHOOTING
PROBLEM POSSIBLE CAUSE SOLUTION
Vehicle does not move
Batteries are not installed properly in the
transmitter
Ensure the transmitter batteries are properly
installed
Weak or no battery in the vehicle Install a freshly charged vehicle battery
Damaged motor Replace the motor
Frayed or broken wiring Replace any damaged wiring
ESC is shut down by heat protection circuit Allow the ESC to cool down completely
Loss of vehicle control
Improper antenna placement
Ensure the transmitter antenna is not blocked
and the receiver antenna is located properly
Weak or no batteries in the transmitter
or vehicle
Install a freshly charged vehicle battery and
new transmitter batteries
Neutral or trim position is incorrect Adjust the steering trim
Receiver and/or battery not connected properly Check all receiver and battery connections
Steering and/or throttle
function is reversed
Servo travel is reversed at the transmitter
Set the transmitter servo reversing switch to
the correct position
Motor wires are not connected properly
Check all motor wires for correct polarity and
secure connection
AXI200012 XC-1 Body, Clear: AX24
AXI201004 Chassis Set: AX24
AXI201005 Body Post Set: AX24
AXI201006 Rock Sliders: AX24
AXI202001 Driveshaft Set: AX24
AXI203001 Shock Set,Assembled (4pcs): AX2
AXI204004 Link Set: AX24
AXI206000 3mm Body Clip w/Tab Black (10pc)
AXI206000 3mm Body Clip w/Tab Black (10pc)
AXI31608 SCX24 Transmission (Assembled)
AXI31609 SCX24 Front Axle (Assembled)
AXI31619 AS-1 Micro Servo
AXI40002 1.0 Rockster Whls Blck (4) SCX24
AXI40007 1.0 Rock Lizards 2.44""(62mm)(4)
AXIC1147 AX31147 Nylon Lock Nut 2mm(10)
DYNB0012 Battery 7.4v 350mAh 2s LiPo
DYNC1062 USB Charger LiPo
DYNS1217 SCX24 Motor w/ Pinion
SPMRSLT310 SLT3 Transmitter
SPMXSE2425RX 2-in-1 ESC and SLT Receiver
Optional Parts:
Check the AX24 product page at HorizonHobby.com for the
latest releases
AXI31567 1.0 Nitto Trail Grappler M/T V1 4p
AXI31610 SCX24 Rear Axle (Assembled)
AXI31615 1.0 KMC Machete Wheels 4pcs
AXI40000 1.0 Method MR307 whls(4) SCX24
AXI40001 1.0 BFG KrawlerT/A Tire(4):SCX2
AXI40004 1.0 Nitto Trl Grapp V2 Tire(4)SCX2
DYNH2027 SS Screw Set: Axial SCX24
SPMXC1050 Smart S1500 DC Charger, 1x500W
SPMXC2050 Smart S155 G2 AC 1x55W Charger
SPMXCA309 Adapter: IC3 Battery/JST PH2.0 Dev.
LIMITED WARRANTY
What this Warranty Covers
Horizon Hobby, LLC, (Horizon) warrants to the original
purchaser that the product purchased (the “Product”) will
be free from defects in materials and workmanship for a
period of 2 years from the date of purchase.
What is Not Covered
This warranty is not transferable and does not cover (i)
cosmetic damage, (ii) damage due to acts of God, accident,
misuse, abuse, negligence, commercial use, or due to
improper use, installation, operation or maintenance, (iii)
modification of or to any part of the Product, (iv) attempted
service by anyone other than a Horizon Hobby authorized
service center, (v) Product not purchased from an authorized
Horizon dealer, or (vi) Product not compliant with applicable
technical regulations or (vii) use that violates any applicable
laws, rules, or regulations.
